705-95-07081 Hydraulic Pilot Pump Gear Pump For HD325-7 Dump Trucks
| Description | HD405-7 Hydraulic Pilot Pump, HD325-7 Gear Pump, Dump Trucks Gear Pump |
| Application | Wheel Loader |
| Model | HD325-7, HD405-7 |
| Part No. | 705-95-07081 |
| Quality | China made |
| Weight | 42-48kgs |
| Packing | Pack into export wooden |
| MOQ | 1PC |
| Lead time | About 1-3 working days |
| Payment | TT, Western union, Paypal, Paysend, RMB |
| Warranty | 3 Months |
| Shipping Port | Huangpu Old Port, Shenzhen Yantian,Guangzhou |
Tips: To ensure client buy correct parts from China, parts details like model, part no. pump code, photo or size are required.
more details more good, all these infos are aim to supply you CORRECT parts to fit well with machine.
Parts on group HD325-7 hydraulic gear pump:
| Pos. | Part No | Qty | Parts name | Comments |
| | 705-95-07081 | [1] | Pump Assembly, SDR63+SDR50+SBR6, SDR30-063+050P+ Komatsu | 40 kg. |
| | ["SN: 7590-UP"] |$0. |
| | 705-95-80030 | [1] | Bracket Assembly Komatsu China | |
| | ["SN: 7590-UP", "SCC: C2"] |$1. |
| 1. | 705-95-80040 | [1] | Bracket Komatsu China | |
| | ["SN: 7590-UP", "SCC: C2"] |
| | 705-94-80610 | [1] | Bushing, Drive Komatsu China | |
| | ["SN: 7590-UP", "SCC: C2"] |$3. |
| | 705-94-80620 | [1] | Bushing, Drive Komatsu | 0.54 kg. |
| | ["SN: 7590-UP", "SCC: C2"] |$4. |
| 2. | 705-94-36021 | [1] | Komatsu China | |
| | ["SN: 7590-UP", "SCC: C2"] |
| 3. | 705-94-36610 | [1] | Gear, Drive Komatsu China | |
| | ["SN: 7590-UP", "SCC: C2"] |
| 4. | 705-94-36510 | [1] | Gear, Driven Komatsu China | |
| | ["SN: 7590-UP", "SCC: C2"] |
| 5. | 705-94-80721 | [2] | Plate, Side Komatsu | 0.45 kg. |
| | ["SN: 7590-UP"] |
| 6. | 705-94-80711 | [2] | Plate, Side Komatsu | 0.232 kg. |
| | ["SN: 7590-UP"] |
| 7. | 04020-00820 | [8] | Pin, Dowel Komatsu | 0.056 kg. |
| | ["SN: 7590-UP"] analogs:["802540092"] |
| 8. | 705-94-80770 | [4] | Seal Komatsu | 0.014 kg. |
| | ["SN: 7590-UP"] |
| 9. | 04065-05820 | [1] | Ring, Snap Komatsu | 0.01 kg. |
| | ["SN: 7590-UP"] |
| 10. | 705-94-80820 | [1] | Seal, Oil Komatsu | 0.025 kg. |
| | ["SN: 7590-UP"] |
